KIA Optima 2012 - Manual (Page 366)

7 55
Maintenance
Fuse Name Fuse rating Circuit Protected
HORN 15A EMS Box (Horn Relay), E/R Fuse & Relay Box (B/Horn Relay)
F/PUMP 20A EMS Box (F/Pump Relay)
ECU 3 15A PCM
SNSR 1 15A Oxygen Sensor (Up/Down), E/R Fuse & Relay Box (C/FAN (HI/LO) Relay)
INJECTOR 10A EMS Box (F/Pump Relay)
SNSR 3 10A Camshaft Position Sensor #1, #2, Immobilizer Module
SNSR 2 10A
RCV Control Solenoid Valve(G4KH), Variable Intake Solenoid Valve(G4KJ),
Canister Close Valve Oil Control Valve #1, #2, Purge Control Solenoid Valve,
Crankshaft Position Sensor
IGN COIL 20A Condenser, Ignition Coil #1, #2, #3, #4
ECU 1 30A EMS Box (Engine Control Relay)
Engine compartment fuse panel (EMS BOX)
