Peerless-AV PTM200 - Installation - Manual (Page 3)

3 of 8 ISSUED: 11-01-11 SHEET #: 021-9012-4 06-04-13
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
Black
Description Qty. Part #
A main plate 1 021-1045
B side clamp 2 021-1052
C top clamp 1 021-1054
D bottom clamp 1 021-1069
E plastic cover 2 590-1347
F washer 7 540-2003
G M5 x 8mm self tapping phillips screw 11 520-1167
H 1/4" spacer 3 600-1215
I M5 x 20mm phillips screw 4 510-1208
J adhesive foam pad 4 570-0045
K 1/2" spacer 4 540-1057
Parts List
A
E
F G H J I K
D
B
C
