BabyTrend 9284 - EXPEDITION DLX - EVEREST Tire Pump - Manual

1. Remove Tire Pump from
storage location, remove
flexible air hose (Fig. 1)
from end of pump (Fig. 2),
thread small brass fitting
into opposite end of
pump (Fig. 3), thread air
nozzle tip onto valve stem
of rim (Fig. 4), now you're
ready to pump up
your tires.
2. Hold the body of Tire
Pump and pull back on
the handle, press down on
handle pushing air into
tire. Repeat until tire is at
20 pounds.
If you experience any difficulty in
using this product, please contact
our customer service department
at 1-800-328-7363 between the
hours of 8:00 am and 4:30 pm
(PST) for assistance.
Tire Pump Instruction
Flexible air hose inside
Remove flexible air hose
Valve stem of rim Small brass fitting
Fig. 1
Fig. 2
Fig. 3
Fig. 4
