Page 6

ASSEMBLY

ATTENTION:

Playard must be fully assembled and securely

locked before installing or using the bassinet

feature. (See To Assemble Playard section)
You will need to remove the mattress from the

bottom of the Playard to use inside your Bassinet.

1. Position the Bassinet over and down into the

fully assembled Playard. Secure in place by

pushing down firmly on each plastic support

clip until all are snapped into place (Fig. 18).

2. Assemble Mattress Support Tubes

(if

equipped; otherwise, skip to step 4)

inserting the two (2) male tubes into the two

(2) female tubes (Fig. 19).

3. Insert both, assembled, Mattress Support

Tubes into the loops provided on the bottom

of the Bassinet (Fig. 20).

4. Place the Mattress into the Bassinet with the

padded side facing upward (Fig. 21)

NOTE: Fasten tabs underneath the Mattress

secure it in place.

TO REMOVE BASSINET

1. Remove Mattress from Bassinet.

2. Remove Canopy.

3. Unsnap all clips and lift Bassinet.

Fig. 18

Fig. 19

Fig. 20

Fig. 21

Bassinet

Metal Support Tubes

(2 male, 2 female)

TO ASSEMBLE BASSINET

(a)

(b)

(c)

Fig. 22

Fig. 23

Fig. 24

WARNING

FALL HAZARD:

prevent death or serious injury,

always keep child within arm's

reach.
Always use restraint belt to prevent

falls, see page 15 for details.

Contents:

(a) 2 Long Curved Bars

(b) 2 Short Bar with Connector Knobs

ATTENTION:

Playard must be fully assembled and securely

locked before installing or using the changing

table feature. (See To Assemble Playard section)

1. Connect the two (2) Long Curved Bars

together (Fig. 22).

2. Insert the assembled curved bars into the

Changing Table fabric (Fig. 23) Slide the

Curved Bars around inside sleeve of the

Changing Table.

3. Connect the two (2) Short Bars to each end

of the Long Curved Bar (Fig. 24) Make sure

that the knobs are both facing down and the

same direction on each end. (Fig. 25)

Fig. 25

TO ASSEMBLE CHANGING TABLE
