BabyTrend 1963CT - ZANZIBAR TRAVEL SYSTEM - Manual (Page 4)

* To attach the front child tray, push the angled tray onto the post at the
end of right armrest, while pressing downward on the snap button, until
locked into place. Please see figure 7. Rotate the tray downward until
latched onto the left armrest. Please check that the snap button comes
through and securely latches the tray in place. Please see figure 8.
* To remove front child tray, press inward on the left side tray release
button and rotate upward on the tray. Please see figure 9. Please note
that you may remove the tray completely by depressing the snap button
on the right side as shown in figure 10 while pulling forward on the tray.
Please see figure 7.
* To attach the parent tray, align the fittings on the ends of the parent
tray with the fittings on the outsides of the handle. Push downward
on the tray until locked into place. Please see figure 11. To remove
the parent tray, pull outward on the bottom edges of the tray and lift
upward. Please see figure 12.
* To install foot rest, line up the foot rest with the stroller frame and push
onto the frame. Please see figure 12A.
* Next, slide the foot rest down onto the protruding rivets until snaps into
place. Please see figure 12B.
* The storage basket swings downward to allow easy access to the basket
contents. Lift upward on the rear tube of the basket to lock in the up
position. Please see figure 13. To lower the basket, pull rearward on
the center of the basket tube and press downward. Please see figure
14.
* Push forward on the front frame of the canopy to open. Please see
figure 15.
4
Figure 9.
Figure 7.
Figure 8.
Figure 11.
Figure 12.
Figure 13.
Figure 14.
Figure 10.
Figure 15.
Front frame
tube
Figure 12A. Figure 12B.
