5
To achieve the best possible sound from this subwoofer enclosure, We recommend
aquiring the services of a professional car audio installation center.
If you feel confident in your ability to install this product without the assistance of a
professional, please read this section thoroughly. We have provided a number of
placement recommendations and installation tips to assist you. Keep in mind these
are provided as a guideline and you may find that other placements specific to your
vehicle may provide better results.
• Make sure all moving parts and factory electrical wires are out of the way and will not
interfere after installation.
• Ensure the wire is of sufficient length to avoid pulling or stretching. This is even more
important if the wires will be run under or through the factory interior.
• Use electrical tape and wire ties to ensure all wires are properly secured.
• Avoid installing speakers or electronics where they can be subject to moisture.
• Ensure the speaker wires are connected using correct polarity. The positive polarity is
marked by a (+) sign. Incorrectly connected subwoofers will result in limited bass
output.
• Speaker wire should be isolated from the vehicle’s electrical system to avoid noise
being picked up by the amplifiers.
• We recommend using 14 gauge or larger sized speaker wire to ensure your subwoofer
receives the full power output of your amplifier.
• Remember to listen responsibly and respect your ears. Being exposed to sounds over
125dB for even short periods of time can create permanent hearing loss!
Dimensions
Enclosure Guidelines
INSTALLATION
5.71" 145mm 6.50" 165mm
10.24" 260mm
9.05" 230mm
10.24 260mm "
DSW101D
DSD102D
6.1
1" 155mm
6.89" 175mm
12.44" 316mm
10.95" 278mm
12.44" 316mm
DSW121D
DSD122D
