9
Power / Open
Volume
Volume Memory
Mute
Mode
Reset
3.5mm A/V Input
USB Port
Main Menu
Momentarily press to turn the unit on. Press and hold for 2 seconds
to turn the unit off. When the unit is on, pressing will open or close the
monitor.
Rotate the volume knob to increase or decrease the volume level (0-39).
If the volume level is <21 when the unit is turned off, it will be retained in
memory the next time the unit is turned on. If the volume level is >20 when the
unit is turned off, the volume level will automatically default to 20 the next time
the unit is turned on.
Momentarily press MUTE to silence the audio. Momentarily press MUTE again
to return to the previously selected volume. Rotating the volume knob while the
volume is muted will also cancel the mute function.
Press MODE to step through all available input modes: Tuner, Disc (which
includes DVD and CD playback), iPod, SD, USB, AV1 and AV2. Modes of
operation are indicated on the display and/or the monitor. Optional iPod device,
USB flash drive and SD card must be connected/inserted to appear in the mode
selection string.
To resolve abnormal operation or if the unit is inoperable, use the tip of a pen
to press the RESET button. The unit will reset the main processor to the default
settings.
Connect external audio/video devices to the 3.5mm auxiliary A/V input on the
front panel.
Connect a USB device to play MP3/WMA files or view JPG photos. The
XDVD1170's USB port supports USB playback only. To connect a phone or other
device for charging, use the USB port on the back of the unit.
When the monitor is open, press the arrow in the top right corner to access the
Main Menu screen.
From the Main Menu screen:
- View/select any operational mode by touching the corresponding icon.
- Enter standby mode by pressing STANDBY.
- Use the up and down arrows to adjust the angle of the screen
- Select SETUP to enter the Setup menu.
General Operation
XDVD1170 OPERATION
