X2DMA400

OPERATION

Control Locations - Receiver

Source / Power ( )

Eject

Mute / Tag

Display

Volume Knob

Back / Band

Select

Audio / Menu

Tuning Knob

Auxiliary Input

SD Card Slot

1
2
3

4
5
6

USB Port

Preset 6 / Folder Up

Preset 5 / Folder Down

Preset 4 / Play / Pause

Preset 3 / Intro

Preset 2 / Random

Preset 1 / Repeat

Tune / Track Up

Reset

Tune / Track Down
