Note:
1. This parameter is characterized and is not 100% tested.
Note:
1. V
IL
and V
IH
max are reference only and are not tested.
Pin Capacitance
Applicable over recommended operating range from T
A
= 25
°
C, f = 20.0 MHz, V
CC
= +3.6V (unless otherwise noted).
Symbol
Test Conditions
Max
Units
Conditions
C
OUT
Output Capacitance (SO)
8
pF
V
OUT
= 0V
C
IN
Input Capacitance (CS, SCK, SI, WP, HOLD)
6
pF
V
IN
= 0V
DC Characteristics (Preliminary – Subject to Change)
Applicable over recommended operating range from: T
AI
= -40 to +85
°
C, V
CC
= +2.7 to +3.6V,
T
AC
= 0 to +70
°
C, V
CC
= +2.7 to +3.6V (unless otherwise noted).
Symbol
Parameter
Test Condition
Min
Typ
Max
Units
V
CC
Supply Voltage
2.7
3.6
V
I
CC1
Supply Current
V
CC
= 3.6V at 20 MHz, SO = Open Read
10.0
15.0
mA
I
CC2
Supply Current
V
CC
= 3.6V at 20 MHz, SO = Open Write
25.0
35.0
mA
I
SB
Standby Current
V
CC
= 2.7V, CS = V
CC
2.0
10.0
µA
I
IL
Input Leakage
V
IN
= 0V to V
CC
-3.0
3.0
µA
I
OL
Output Leakage
V
IN
= 0V to V
CC
, T
AC
= 0
°
C to 70
°
C
-3.0
3.0
µA
V
IL
Input Low Voltage
-0.6
V
CC
x 0.3
V
V
IH
Input High Voltage
V
CC
x 0.7
V
CC
+ 0.5
V
V
OL
Output Low Voltage
2.7V
≤
V
CC
≤
3.6V
I
OL
= 0.15 mA
0.2
V
V
OH
Output High Voltage
I
OH
= -100 µA
V
CC
- 0.2
V
