APExx04 Series
Rev 1.4 2004/4/20
4
FIGURE 2 : Frequency vs. Rosc (at 3V)
Resistor (Rosc ohms)
110k
200k
300k
430k
Frequency (MHz)
14.84 8.25 5.54
3.92
5.0 Application
Circuit
Rosc vs Freq.
5.54
3.92
8.25
14.84
0
5
10
15
20
0
100
200
300
400
500
R osc (k ohm )
Freq. (MHz)
xxxx
