CPU Trigger Mode
Up to 32 Voice Groups can be triggered by supplying address to [S5:S1] with SBT as strobe signal.
Voice Group S8 S7 S6 S5 S4 S3 S2 S1
1 NC NC NC 0 0 0 0 0
2 NC NC NC 0 0 0 0 1
3 NC NC NC 0 0 0 1 0
4 NC NC NC 0 0 0 1 1
5 NC NC NC 0 0 1 0 0
6 NC NC NC 0 0 1 0 1
7 NC NC NC 0 0 1 1 0
8 NC NC NC 0 0 1 1 1
9 NC NC NC 0 1 0 0 0
10 NC NC NC 0 1 0 0 1
11 NC NC NC 0 1 0 1 0
12 NC NC NC 0 1 0 1 1
13 NC NC NC 0 1 1 0 0
14 NC NC NC 0 1 1 0 1
15 NC NC NC 0 1 1 1 0
16 NC NC NC 0 1 1 1 1
17 NC NC NC 1 0 0 0 0
18 NC NC NC 1 0 0 0 1
19 NC NC NC 1 0 0 1 0
20 NC NC NC 1 0 0 1 1
21 NC NC NC 1 0 1 0 0
22 NC NC NC 1 0 1 0 1
23 NC NC NC 1 0 1 1 0
24 NC NC NC 1 0 1 1 1
25 NC NC NC 1 1 0 0 0
26 NC NC NC 1 1 0 0 1
27 NC NC NC 1 1 0 1 0
28 NC NC NC 1 1 0 1 1
29 NC NC NC 1 1 1 0 0
30 NC NC NC 1 1 1 0 1
31 NC NC NC 1 1 1 1 0
32 NC NC NC 1 1 1 1 1
