Voice Recording & Playback Device

Revision 1.0

Pin Descriptions

Table three shows pin descriptions for the

APR6016

device.

All pins are listed in numerical order with the exception of

VCC, VSS and NC pins which are listed at the end of the
table.

Table 3 APR6016 28 Pin Number & Description

Pin Name

Pin No.

28 pin

DIP

Pad No. (Die)

Reference Figure

18

Functionality

SAC 24 27 Sector Address Control Output: This active low output indicates when the

device is nearing the end of the current segment.

/INT 25 28 Interrupt Output: This active low open drain output goes low whenever the

device reaches the end of a message or the device overflows. When connected
to the interrupt input of the host microcontroller this output can be used to imple-
ment powerful message management options.

EXTCLK 26 29 External Clock Input: This input can be used to feed the device an external

sample clock instead of using the internal sampling clock. This pin should be con-
nected to VSSA when not in use.

SCLK 28 33 SPI Clock Input: Data is clocked into the device through the DI pin upon the ris-

ing edge of this clock. Data is clocked out of the part through the DO pin on the
falling edge.

/CS 1 2 Chip Select Input: This active low input selects the device as the currently active

slave on the SPI interface. When this pin is high the device tri-states the DO pin
and ignores data on the DI pin.

DI 2 3 Data Input: The DI input pin receives the digital data input from the SPI bus.

Data is clocked on the rising edge of the SCLK input.

DO 3 4 Data Output: Data is available after the falling edge of the SCLK input.

ANAOUT- 8 9 Negative Audio Output: This is the negative audio output for playback of pre-

recorded messages. This output is usually fed to the negative input of a differen-
tial input power amplifier. The power amplifier drives an external speaker.

ANAOUT+ 9 10 Positive Audio Output: This is the positive audio output for playback of pre-

recorded messages. This output is usually fed to the positive input of a differential
input power amplifier. The power amplifier drives an external speaker.

/RESET 11 11 Reset Input: This active low input clears all internal address registers and

restores the device to its power up defaults.

AUDOUT 13 15 Single Ended Audio Output: This is the audio output for playback of pre-

recorded messages. This output is usually fed to the input of a power amplifier for
driving an external speaker.

SQLCAP 14 16 Squelch Capacitor I/O: This pin controls the attack time of the squelch circuitry.

Connect this pin to GND through a 1.0 uf capacitor to enable the squelch feature.
The capacitor’s time constant will affect how quickly the squelch circuitry reacts.

Connect this pin to VCCA to disable the squelch feature.

/SQLOUT 15 17 Squelch Output: This active low open drain output indicates when the internal

squelch circuitry has activated. This signal can be used to automatically squelch
the external power amplifier. Squelching the external power amplifier can result in
an even greater reduction of background noise.

ANAIN- 16 18 Inverting Analog Input: This input is the inverting input for the analog signal that

the user wishes to record. When the device is used in a differential input configu-
ration this pin should receive a 16 mV peak to peak input coupled through a
0.1uF capacitor. When the device is used in a single ended input configuration
this input should be tied to VSSA through a 0.1 uF capacitor.
