ISD18B12
Publication Release Date: August 31, 2007
- 11 - Revision A1
6. ABSOLUTE MAXIMUM RATINGS
ABSOLUTE MAXIMUM RATINGS [1]
CONDITION VALUE
Junction temperature 150°C
Storage temperature range -65°C to +150°C
Voltage applied to any pins (V
SS
– 0.3V) to (V
CC
+ 0.3V)
Voltage applied to Input pins (current limited to +/-20 mA) (V
SS
– 1.0V) to (V
CC
+ 1.0V)
Voltage applied to output pins (current limited to +/-20 mA) (V
SS
– 1.0V) to (V
CC
+ 1.0V)
V
CC
– V
SS
-0.3V to +7.0V
[1] Stresses above those listed may cause permanent damage to the device. Exposure
to the absolute maximum ratings may affect device reliability and performance.
Functional operation is not implied at these conditions.
6.1 O PERATING C ONDITIONS
OPERATING CONDITIONS
CONDITION VALUE
Operating temperature range 0°C to +50°C
Operating voltage (V
CC
) [1] +2.4V to +5.5V
Ground voltage (V
SS
) [2] 0V
[1] V
CC
= V
CCA
= V
CCD
[2] V
SS
= V
SSA
= V
SSD
