Converter Electrical Characteristics

(Continued)

Unless otherwise specified, the following specifications apply for AGND = DGND = DR GND = 0V, V

A

= V

D

= +3.3V,

V

DR

= +2.5V, PD = 0V, V

REF

= +1.0V, V

CM

= 1.0V, f

CLK

= 66 MHz, t

r

= t

f

= 2 ns, C

L

= 15 pF/pin. Boldface limits apply for T

J

= T

MIN

to T

MAX

: all other limits T

J

= 25˚C (Notes 7, 8, 9, 10)

Symbol

Parameter

Conditions

Typical

(Note 10)

Limits

(Note 10)

Units

(Limits)

DYNAMIC CONVERTER CHARACTERISTICS

BW

Full Power Bandwidth

0 dBFS Input, Output at −3 dB

450

MHz

SNR

Signal-to-Noise Ratio

f

IN

= 10 MHz, V

IN

=

−0.5 dBFS

85˚C

66

64.6

dB (min)

25˚C

65

dB (min)

−40˚C

64.6

dB (min)

f

IN

= 25 MHz, V

IN

=

−0.5 dBFS

65

dB

f

IN

= 150 MHz, V

IN

= −6 dBFS

85˚C

55

52

dB (min)

25˚C

54

dB (min)

−40˚C

51

dB (min)

f

IN

= 240 Hz, V

IN

=

−6 dBFS

52

dB

SINAD

Signal-to-Noise & Distortion

f

IN

= 10 MHz, V

IN

=

−0.5 dBFS

85˚C

66

64.3

dB (min)

25˚C

64.8

dB (min)

−40˚C

63

dB (min)

f

IN

= 25 MHz, V

IN

=

−0.5 dBFS

64

dB

f

IN

= 150 MHz, V

IN

= −6 dBFS

85˚C

55

51.8

dB (min)

25˚C

53.9

dB (min)

−40˚C

50

dB (min)

f

IN

= 240 Hz, V

IN

=

−6 dBFS

51

dB

ENOB

Effective Number of Bits

f

IN

= 10 MHz, V

IN

=

−0.5 dBFS

85˚C

10.7

10.3

25˚C

10.5

Bits (min)

−40˚C

10.2

f

IN

= 25 MHz, V

IN

=

−0.5 dBFS

10.3

Bits

f

IN

= 150 MHz, V

IN

= −6 dBFS

85˚C

8.8

8.3

25˚C

8.6

Bits (min)

−40˚C

8.0

f

IN

= 240 Hz, V

IN

=

−6 dBFS

8.2

Bits

ADC12L066

www.national.com

6
