DS1720
030598 10/12
ABSOLUTE MAXIMUM RATINGS*
Voltage on Any Pin Relative to Ground
–0.5V to +7.0V
Operating Temperature
–55
°
C to +125
°
C
Storage Temperature
–55
°
C to +125
°
C
Soldering Temperature
260
°
C for 10 seconds
* This is a stress rating only and functional operation of the device at these or any other conditions above those
indicated in the operation sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods of time may affect reliability.
The Dallas Semiconductor DS1720 is built to the highest quality standards and manufactured for long term reliability.
All Dallas Semiconductor devices are made using the same quality materials and manufacturing methods. However,
the DS1720 is not exposed to environmental stresses, such as burn–in, that some industrial applications require. For
specific reliability information on this product, please contact the factory in Dallas at (972) 371–4448.
RECOMMENDED DC OPERATING CONDITIONS
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
NOTES
Supply
V
DD
2.7
5.5
V
1
Logic 1
V
IH
2.0
V
CC
+0.3
V
1
Logic 0
V
IL
–0.3
+0.6
V
1
DC ELECTRICAL CHARACTERISTICS
(–55
°
C to +125
°
C; V
DD
=2.7V to 5.5V)
PARAMETER
SYMBOL
CONDITION
MIN
MAX
UNITS
NOTES
Thermometer Error
T
ERR
0
°
C to 85
°
C
±
2.5
°
C
10, 11
–55
°
C to
+125
°
C
See Typical Curve
Logic 0 Output
V
OL
0.4
V
3
Logic 1 Output
V
OH
2.4
V
2
Input Resistance
R
I
RST to GND
DQ,CLK to V
DD
2
2
M
Ω
M
Ω
Active Supply Current
I
CC
0
°
C to +70
°
C
1
mA
4, 5
Standby Supply Current
I
STBY
0
°
C to +70
°
C
1
µ
A
4, 5
SINGLE CONVERT TIMING DIAGRAM (STAND–ALONE MODE)
t
CNV
CONV
