AT89S51

2487A–10/01

Notes:

1. The signature bytes are not readable in Lock Bit Modes 3 and 4.
2. B1 = 0, B2 = 0

Mode 1, no lock protection

B1 = 0, B2 = 1

Mode 2, lock bit 1 activated

B1 = 1, B2 = 0

Mode 3, lock bit 2 activated

B1 = 1, B1 = 1

Mode 4, lock bit 3 activated

After Reset signal is high, SCK should be low for at least 64 system clocks before it goes high to clock in the enable data

bytes. No pulsing of Reset signal is necessary. SCK should be no faster than 1/16 of the system clock at XTAL1.

For Page Read/Write, the data always starts from byte 0 to 255. After the command byte and upper address byte are

latched, each byte thereafter is treated as data until all 256 bytes are shifted in/out. Then the next instruction will be ready to
be decoded.

Table 8. Serial Programming Instruction Set

Instruction

Instruction
Format

Operation

Byte 1

Byte 2

Byte 3

Byte 4

Programming Enable

1010 1100

0101 0011

xxxx xxxx

xxxx xxxx
0110 1001
(Output)

Enable Serial Programming
while RST is high

Chip Erase

1010 1100

100x xxxx

xxxx xxxx

xxxx xxxx

Chip Erase Flash memory
array

Read Program Memory
(Byte Mode)

0010 0000

xxxx

Read data from Program
memory in the byte mode

Write Program Memory
(Byte Mode)

0100 0000

xxxx

Write data to Program
memory in the byte mode

Write Lock Bits

(2)

1010 1100

1110 00

xxxx xxxx

xxxx xxxx

Write Lock bits. See Note (2).

Read Lock Bits

0010 0100

xxxx xxxx

xxxx xxxx

xx

xx

Read back current status of
the lock bits (a programmed
lock bit reads back as a “1”)

Read Signature Bytes

(1)

0010 1000

xxx

xxx xxxx

Signature Byte

Read Signature Byte

Read Program Memory
(Page Mode)

0011 0000

xxxx

Byte 0

Byte 1...
Byte 255

Read data from Program
memory in the Page Mode
(256 bytes)

Write Program Memory
(Page Mode)

0101 0000

xxxx

Byte 0

Byte 1...
Byte 255

Write data to Program
memory in the Page Mode
(256 bytes)

}

Each of the lock bits needs to be activated sequentially before
Mode 4 can be executed.

D7 D6 D5 D4

D3 D2 D1 D0

A7 A6 A5 A4

A3 A2 A1 A0

A1

1

A10

A9 A8

B2

B1

A11 A10

A9 A8

A7 A6 A5 A4

A3 A2 A1 A0

D7 D6 D5 D4

D3 D2 D1 D0

LB3

LB

2

LB1

A5

A4 A3 A2

A1

A1

1

A10

A9 A8

A1

1

A10

A9 A8

A0
