DS1996
16 of 18
READ/WRITE TIMING DIAGRAM Figure 11 (cont’d)
Write-Zero Time Slot
Regular Speed Overdrive Speed
60
µ
s
≤
t
LOW0
< t
SLOT
< 120
µ
s 6
µ
s
≤
t
LOW0
< t
SLOT
< 16
µ
s
1
µ
s
≤
t
REC
<
∞
1
µ
s
≤
t
REC
<
∞
Read-Data Time Slot
Regular Speed Overdrive Speed
60
µ
s
≤
t
SLOT
< 120
µ
s 6
µ
s
≤
t
SLOT
< 16
µ
s
1
µ
s
≤
t
LOWR
< 15
µ
s 1
µ
s
≤
t
LOWR
< 2
µ
s
0
≤
t
RELEASE
< 45
µ
s 0
≤
t
RELEASE
< 4
µ
s
1
µ
s
≤
t
REC
<
∞
1
µ
s
≤
t
REC
<
∞
t
RDV
= 15
µ
s t
RDV
= 2
µ
s
t
SU
< 1
µ
s t
SU
< 1
µ
s
RESISTOR
MASTER
DS1996
