MAX6375–MAX6380
3-Pin, Ultra-Low-Power SC70/SOT23
Voltage Detectors
6 _______________________________________________________________________________________
___________________Chip Information
TRANSISTOR COUNT: 419
Table 2. Device Marking Codes and Minimum Order Increments (continued)
Selector Guide
(Standard Versions**)
**Sample stock is generally held on all standard versions.
Contact factory for availability of nonstandard versions.
PART
TOP MARK
(SC70)
TOP MARK
(SOT23)
ORDER
INCREMENT (k)
MAX6378_R39-T — — 10
MAX6378_R40-T — — 10
MAX6378_R41-T — — 10
MAX6378_R42-T — — 10
MAX6378_R43-T — — 10
MAX6378_R44-T ADS FZHU 2.5
MAX6378_R45-T — — 10
MAX6378_R46-T ADD FZHV 2.5
MAX6379_R33-T — — 10
MAX6379_R34-T — — 10
MAX6379_R35-T — — 10
MAX6379_R36-T — — 10
MAX6379_R37-T — — 10
MAX6379_R38-T — — 10
MAX6379_R39-T — — 10
MAX6379_R40-T — — 10
MAX6379_R41-T — — 10
MAX6379_R42-T — — 10
PART
TOP MARK
(SC70)
TOP MARK
(SOT23)
ORDER
INCREMENT (k)
MAX6379_R43-T — — 10
MAX6379_R44-T ADE FZHW 2.5
MAX6379_R45-T — — 10
MAX6379_R46-T ADT FZHX 2.5
MAX6380_R33-T — — 10
MAX6380_R34-T — — 10
MAX6380_R35-T — — 10
MAX6380_R36-T — — 10
MAX6380_R37-T — — 10
MAX6380_R38-T — — 10
MAX6380_R39-T — — 10
MAX6380_R40-T — — 10
MAX6380_R41-T — — 10
MAX6380_R42-T — — 10
MAX6380_R43-T — — 10
MAX6380_R44-T ADU FZHY 2.5
MAX6380_R45-T — — 10
MAX6380_R46-T ADF FZHZ 2.5
PART NOMINAL V TH (V)
MAX63 _ _ _ R46-T 4.63
MAX63 _ _ _ R44-T 4.38
MAX63 _ _ _ R31-T 3.08
MAX63 _ _ _ R29-T 2.93
MAX63 _ _ _ R26-T 2.63
MAX63 _ _ _ R23-T 2.32
MAX63 _ _ _ R22-T 2.20
Ordering Information (continued)
PART* TEMP RANGE PIN-PACKAGE
MAX6377UR _ _ -T -40°C to +85°C 3 SOT23-3
MAX6377XR _ _ -T -40°C to +85°C 3 SC70-3
MAX6378UR _ _ -T -40°C to +85°C 3 SOT23-3
MAX6378XR _ _ -T -40°C to +85°C 3 SC70-3
MAX6379UR _ _ -T -40°C to +85°C 3 SOT23-3
MAX6379XR _ _ -T -40°C to +85°C 3 SC70-3
MAX6380UR _ _ -T -40°C to +85°C 3 SOT23-3
MAX6380XR _ _ -T -40°C to +85°C 3 SC70-3
* The MAX6375/MAX6376/MAX6377 are available in factory-pre-
set thresholds from 2.20V to 3.08V, in approximately 0.1V incre-
ments. The MAX6378/MAX6379/MAX6380 are available in
factory-preset thresholds from 3.30V to 4.63V, in approximately
0.1V increments. Choose the desired threshold suffix from Table
1 and insert it in the blank spaces following R. There are 21 stan-
dard versions, with a required order increment of 2500 pieces.
Sample stock is generally held on the standard versions only
(see the Selector Guide). The required order increment is 10,000
pieces for nonstandard versions (Table 2). Contact factory for
availability. All devices available in tape-and-reel only.
