3-Pin, Ultra-Low-Power SC70/SOT23
Voltage Detectors
_______________________________________________________________________________________ 5
Table 1. Factory-Trimmed Reset Thresholds ‡ (continued)
‡ Factory-trimmed reset thresholds are available in approximately 100mV increments with a 1.5% room-temperature variance.
Table 2. Device Marking Codes and Minimum Order Increments
RESET THRESHOLD VOLTAGE, V TH (V)
T A = +25°C T A = -40°C TO +85°C PART SUFFIX
MIN TYP MAX MIN MAX
33 3.250 3.300 3.350 3.217 3.383
34 3.349 3.400 3.451 3.315 3.485
35 3.447 3.500 3.552 3.412 3.587
36 3.546 3.600 3.654 3.510 3.690
37 3.644 3.700 3.755 3.607 3.792
38 3.743 3.800 3.857 3.705 3.895
39 3.841 3.900 3.958 3.802 3.997
40 3.940 4.000 4.060 3.900 4.100
41 4.038 4.100 4.161 3.997 4.202
42 4.137 4.200 4.263 4.095 4.305
43 4.235 4.300 4.364 4.192 4.407
44 4.314 4.380 4.446 4.270 4.489
45 4.432 4.500 4.567 4.387 4.612
MAX6378_R
MAX6379_R
MAX6380_R
46 4.560 4.630 4.699 4.514 4.746
PART
TOP MARK
(SC70)
TOP MARK
(SOT23)
ORDER
INCREMENT (k)
MAX6375_R22-T ADH FZHD 2.5
MAX6375_R23-T ADI FZHE 2.5
MAX6375_R24-T — — 10
MAX6375_R25-T — — 10
MAX6375_R26-T ACZ FZHC 2.5
MAX6375_R27-T — — 10
MAX6375_R28-T — — 10
MAX6375_R29-T ADJ FZHF 2.5
MAX6375_R30-T — — 10
MAX6375_R31-T ADK FZHG 2.5
MAX6376_R22-T ADL FZHH 2.5
MAX6376_R23-T ADM FZHI 2.5
MAX6376_R24-T — — 10
MAX6376_R25-T — — 10
MAX6376_R26-T ADN FZHJ 2.5
MAX6376_R27-T — — 10
MAX6376_R28-T — — 10
MAX6376_R29-T ADA FZHK 2.5
PART
TOP MARK
(SC70)
TOP MARK
(SOT23)
ORDER
INCREMENT (k)
MAX6376_R30-T — — 10
MAX6376_R31-T ADO FZHL 2.5
MAX6377_R22-T ADP FZHM 2.5
MAX6377_R23-T ADB FZHN 2.5
MAX6377_R24-T — — 10
MAX6377_R25-T — — 10
MAX6377_R26-T ACQ FZHO 2.5
MAX6377_R27-T — — 10
MAX6377_R28-T — — 10
MAX6377_R29-T ADC FZHP 2.5
MAX6377_R30-T — — 10
MAX6377_R31-T ADR FZHQ 2.5
MAX6378_R33-T — — 10
MAX6378_R34-T — — 10
MAX6378_R35-T — — 10
MAX6378_R36-T — — 10
MAX6378_R37-T — — 10
MAX6378_R38-T — — 10
MAX6375–MAX6380
