General Description
The MAX16041/MAX16042/MAX16043 are dual-/triple-/
quad-voltage monitors and sequencers that are offered
in a small thin QFN package. These devices offer enor-
mous design flexibility as they allow fixed and
adjustable thresholds to be selected through logic
inputs and provide sequence timing through small
external capacitors. These versatile devices are ideal
for use in a wide variety of multivoltage applications.
As the voltage at each monitored input exceeds its
respective threshold, its corresponding output goes
high after a propagation delay or a capacitor-set time
delay. When a voltage falls below its threshold, its
respective output goes low after a propagation delay.
Each detector circuit also includes its own enable input,
allowing the power-good outputs to be shut off inde-
pendently. The independent output for each detector
has an open-drain configuration capable of supporting
voltages up to 28V, thereby allowing them to interface
to shutdown and enable inputs of various DC-DC regu-
lators. Each detector can operate independently as four
separate supervisory circuits or can be daisy-chained
to provide controlled power-supply sequencing.
The MAX16041/MAX16042/MAX16043 also include a
push-pull reset function that deasserts only after all of
the independently monitored voltages exceed their
threshold. The reset timeout is internally fixed or can be
adjusted externally. These devices are offered in a
4mm x 4mm TQFN package and are fully specified
from -40°C to +125°C.
Applications
Multivoltage Systems
DC-DC Supplies
Servers/Workstations
Storage Systems
Networking/Telecommunication Equipment
Features
♦ 2.2V to 28V Operating Voltage Range
♦ Fixed Thresholds for 3.3V, 2.5V, 1.8V, 1.5V, and
1.2V Systems
♦ 1.5% Accurate Adjustable Threshold Monitors
Voltages Down to 0.5V
♦ 2.7% Accurate Fixed Thresholds Over
Temperature
♦ Fixed (140ms min)/Capacitor-Adjustable Delay
Timing
♦ Independent Open-Drain Outputs/Push-Pull
RESET Output
♦ Enable Inputs for Each Monitored Voltage
♦ 9 Logic-Selectable Threshold Options
♦ Manual Reset and Tolerance Select (5%/10%) Inputs
♦ Small, 4mm x 4mm TQFN Package
♦ Fully Specified from -40°C to +125°C
MAX16041/MAX16042/MAX16043
Dual-/Triple-/Quad-Voltage, Capacitor-
Adjustable, Sequencing/Supervisory Circuits
________________________________________________________________ Maxim Integrated Products 1
TOP VIEW
+
23
24
22
21
8
7
9
IN1 IN3 IN4 TOL
10
V
CC
OUT1 OUT3 OUT4 RESET TH0
1 2
CDLY3
4 5 6
17 18 16 14 13
CDLY2
CDLY1
EN3
EN2
EN1
GND
MAX16043
IN2
OUT2
3
15
CDLY4
20 11 EN4 CRESET
19 12 TH1 MR
TQFN
(4mm x 4mm)
Pin Configurations
Ordering Information
19-0622; Rev 0; 8/06
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
+ Denotes lead-free package.
* For tape and reel, add a “T” after the “+.” All tape and reel
orders are available in 2.5k increments.
PART* TEMP RANGE
PIN-
PACKAGE PKG
CODE
MAX16041TE+ -40°C to +125°C 16 TQFN T1644-4
MAX16042TP+ -40°C to +125°C 20 TQFN T2044-3
MAX16043TG+ -40°C to +125°C 24 TQFN T2444-4
Selector Guide
PART
MONITORED
VOLTAGES
INDEPENDENT
OUTPUTS
RESET
OUTPUT
MAX16041 2 2 (Open-drain) Push-pull
MAX16042 3 3 (Open-drain) Push-pull
MAX16043 4 4 (Open-drain) Push-pull
Pin Configurations continued at end of data sheet.
