MAX16025–MAX16030
Dual-/Triple-/Quad-Voltage, Capacitor-
Adjustable, Sequencing/Supervisory Circuits
8 _ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _
LOGIC
1V
250nA
OUT1
OUT2
OUT3
OUT4
RESET
EN1 EN2 EN3 EN4 TH1 TH0
IN1
IN2
IN3
IN4
GND
TOL
DRIVER
DRIVER
DRIVER
DRIVER
DELAY
DELAY
DELAY
DELAY
V CC
CDLY1 CDLY2 CDLY3 CDLY4 CRESET MR
REFERENCE
THRESHOLD
SELECT
LOGIC
RESET
DELAY
LOGIC
DRIVER
MAX16029
MAX16030
Figure 1. MAX16029/MAX16030 Simplified Functional Diagram
