Configuration/Setup Bytes (Write Cycle)
A write cycle begins with the bus master issuing a
START condition followed by seven address bits
(Figure 7) and a write bit (R/W = 0). If the address byte
is successfully received, the MAX11644/MAX11645
(slave) issues an acknowledge. The master then writes
to the slave. The slave recognizes the received byte as
the set-up byte (Table 1) if the most significant bit
(MSB) is 1. If the MSB is 0, the slave recognizes that
byte as the configuration byte (Table 2). The master
can write either one or two bytes to the slave in any
order (setup byte, then configuration byte; configura-
tion byte, then setup byte; setup byte or configuration
byte only; Figure 9). If the slave receives a byte suc-
cessfully, it issues an acknowledge. The master ends
the write cycle by issuing a STOP condition or a repeat-
ed START condition. When operating in HS mode, a
STOP condition returns the bus into F/S mode (see the
HS Mode
section).
B) TWO-BYTE WRITE CYCLE
SLAVE TO MASTER
MASTER TO SLAVE
S
1
SLAVE ADDRESS
A
7
1 1
W
SETUP OR
CONFIGURATION BYTE
SETUP OR
CONFIGURATION BYTE
8
P OR Sr
1
A
1
MSB DETERMINES WHETHER
SETUP OR CONFIGURATION BYTE
S
1
SLAVE ADDRESS
A
7
1 1
W
SETUP OR
CONFIGURATION BYTE
8
P OR Sr
1
A
1
MSB DETERMINES WHETHER
SETUP OR CONFIGURATION BYTE
A
1
8
A) ONE-BYTE WRITE CYCLE
NUMBER OF BITS
NUMBER OF BITS
Figure 9. Write Cycle
BIT 7
(MSB)
BIT 6
BIT 5
BIT 4
BIT 3
BIT 2
BIT 1
BIT 0
(LSB)
REG
SEL2
SEL1
SEL0
CLK
BIP/UNI
RST
X
BIT
NAME
DESCRIPTION
7
REG
Register bit. 1 = setup byte, 0 = configuration byte (Table 2).
6
SEL2
5
SEL1
4
SEL0
Three bits select the reference voltage (Table 6).
Default to 000 at power-up.
3
CLK
1 = external clock, 0 = internal clock. Defaults to 0 at power-up.
2
BIP/UNI
1 = bipolar, 0 = unipolar. Defaults to 0 at power-up (see the Unipolar/Bipolar section).
1
RST
1 = no action, 0 = resets the configuration register to default. Setup register remains unchanged.
0
X
Don’t-care bit. This bit can be set to 1 or 0.
Table 1. Setup Byte Format
