MAX6501–MAX6504
Low-Cost, +2.7V to +5.5V, Micropower
Temperature Switches in SOT23 and TO-220
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
CC
= +2.7V to +5.5V, R
PULL-UP
= 100k
Ω (MAX6501/MAX6503 only), T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are
at T
A
= +25°C.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Note 1: 100% production tested at T
A
= +25°C. Specifications over temperature limits are guaranteed by design.
Note 2: The MAX6501–MAX6504 are available with internal, factory-programmed temperature trip thresholds from -45°C to +115°C
in +10°C increments (see Selector Guide).
Note 3: Guaranteed by design.
Supply Voltage (V
CC
) ...............................................-0.3V to +7V
TOVER (MAX6501) ...................................................-0.3V to +7V
TOVER (MAX6502) .....................................-0.3V to (V
CC
+ 0.3V)
TUNDER (MAX6503) ................................................-0.3V to +7V
TUNDER (MAX6504) ..................................-0.3V to (V
CC
+ 0.3V)
All Other Pins..............................................-0.3V to (V
CC
+ 0.3V)
Input Current (all pins) ........................................................20mA
Output Current (all pins) .....................................................20mA
Continuous Power Dissipation (T
A
= +70°C)
5-Pin SOT23-5 (derate 7.1mW/°C above +70°C) .........571mW
Operating Temperature Range .........................-55°C to +125°C
Storage Temperature Range .............................-65°C to +165°C
Lead Temperature (soldering, 10sec) .............................+300°C
-45°C to -25°C
V
CC
= 2.7V, V
TUNDER
= 5.5V (MAX6503),
V
TOVER
= 5.5V (MAX6501)
-15°C to +15°C
HYST = GND
I
SOURCE
= 500µA, V
CC
> 2.7V
(MAX6502/MAX6504 only)
I
SINK
= 1.2mA, V
CC
> 2.7V
CONDITIONS
-6
±0.5
6
µA
30
85
I
CC
V
2.7
5.5
V
CC
Supply Voltage Range
Supply Current
nA
10
Open-Drain Output Leakage
Current
-4
±0.5
4
2
T
HYST
Temperature Threshold
Hysteresis
V
0.8 x V
CC
0.3
UNITS
MIN
TYP
MAX
SYMBOL
PARAMETER
+35°C to +65°C
+75°C to +115°C
-4
±0.5
4
°C
-6
±0.5
6
∆T
TH
Temperature Threshold
Accuracy (Note 2)
V
0.2 x V
CC
V
IL
HYST Input Threshold
(Note 3)
0.8 x V
CC
V
IH
I
SINK
= 3.2mA, V
CC
> 4.5V
V
0.4
V
OL
Output Voltage Low
HYST = V
CC
10
°C
I
SOURCE
= 800µA, V
CC
> 4.5V
(MAX6502/MAX6504 only)
V
CC
- 1.5
V
OH
Output Voltage High
