MAX14805/MAX14806
16-Channel (Two Banks of 8-Channel),
High-Voltage Analog Switches
19-5253; Rev 0; 4/10
Ordering Information/Selector Guide
General Description
The MAX14805/MAX14806 provide high-voltage switch-
ing on 16 channels for ultrasonic imaging. Both devices
are ideal for the following applications: banks selection in
biplane or triplane ultrasound probes and relays replace-
ment. The devices utilize 200V process technology to
provide sixteen high-voltage, low-charge injection SPST
switches, controlled by a digital interface.
The MAX14805/MAX14806’s output switches are con-
figured as two sets of eight SPST analog switches. The
switches are controlled by two input logic controls, DIN1
and DIN2 (respectively for switch 0 to 7 and switch 8
to 15). The MAX14806 features integrated 40kI bleed
resistors on each switch terminal, which help to reduce
voltage buildup in capacitive loads such as piezoelectric
elements.
The MAX14805/MAX14806 operate with a wide range of
high-voltage supplies, including V
PP /V NN = +100V/-100V,
+200V/0V, and +40V/-160V. The digital interface oper-
ates from a separate V
DD supply from +2.7V to +5.5V.
Digital inputs DIN1, DIN2, and LE operate on the V DD
supply voltage.
The MAX14805CCM+ is a drop-in replacement for the
Supertex HV2631. The MAX14806CCM+ is a drop-in
replacement for the Supertex HV2731. Both devices are
available in the 48-pin, TQFP package and are specified
for the extended -40NC to +85NC temperature range.
Features
S
HVCMOS_Technology_for_High_Performance
S
Two_Sets_of_8-Channel_SPST_High-Voltage_Analog_
Switches
S
DC_to_20MHz_Low-Voltage_Analog_Signal_
Frequency_Range
S
+2.7V_to_+5.5V_Logic_Supply_Voltage
S
Ultra-Low_(0.1µA)_(typ)_Quiescent_Current
S
Low-Charge_Injection,_Low-Capacitance_20I_
Switches
S
-77dB_(typ)_Off-Isolation_at_5MHz_(50I)
S
Flexible,_High-Voltage_Supplies_(V
PP
_-_V
NN
_=_
230V)
Applications
Medical Ultrasound Imaging
Nondestructive Test (NDT)
Note: All devices are specified over the extended -40°C to +85°C operating temperature range.
+Denotes a lead(Pb)-free/RoHS-compliant package.
PART
SWITCH
CHANNELS
BLEED
RESISTOR
SECOND_SOURCE PIN-PACKAGE
MAX14805CCM+ 2 x 8 No HV2631 48 TQFP
MAX14806CCM+ 2 x 8 Yes HV2731 48 TQFP
