MAX5130/MAX5131
+3V/+5V, 13-Bit, Serial Voltage-Output DACs
with Internal Reference
_______________________________________________________________________________________ 7
-0.3
-0.1
-0.2
0.1
0
0.2
0.3
0 4000 2000 6000 8000 10,000
MAX5131
INTEGRAL NONLINEARITY
vs. DIGITAL INPUT CODE
MAX5130/31 toc-13
DIGITAL INPUT CODE
INL (LSB)
-0.25
-0.15
0.05
-0.05
0.15
0.25
4000 2000 6000 8000 10,000
MAX5131
DIFFERENTIAL NONLINEARITY
vs. DIGITAL INPUT CODE
MAX5130/31 toc-14
DIGITAL INPUT CODE
DNL (LSB)
0
1.240
1.242
1.246
1.244
1.248
1.250
-60 -20 0 -40 20 40 60 80 100
MAX5131
REFERENCE VOLTAGE
vs. TEMPERATURE
MAX5130/31 toc-15
TEMPERATURE (°C)
REFERENCE VOLTAGE (V)
100
150
300
250
200
350
400
-60 -20 0 -40 20 40 60 80 100
MAX5131
SUPPLY CURRENT vs. TEMPERATURE
MAX5130/31 toc-16
TEMPERATURE (°C)
SUPPLY CURRENT (
µ
A)
CODE = 1555 HEX
CODE = 0000 HEX
2.036
2.038
2.042
2.040
2.044
2.046
-60 -20 0 -40 20 40 60 80 100
MAX5131
FULL-SCALE OUTPUT vs. TEMPERATURE
MAX5130/31 toc-19
TEMPERATURE (°C)
FULL-SCALE OUTPUT (V)
R L = 5k Ω
C L = 100pF
250
300
275
350
325
375
400
2.5 2.9 3.1 2.7 3.3 3.5 3.7
MAX5131
SUPPLY CURRENT vs. SUPPLY VOLTAGE
MAX5130/31 toc-17
SUPPLY VOLTAGE (V)
SUPPLY CURRENT (
µ A) CODE = 1555 HEX
CODE = 0000 HEX
0
0.2
0.6
0.4
0.8
1.0
-60 -20 0 -40 20 40 60 80 100
MAX5131
SHUTDOWN CURRENT vs. TEMPERATURE
MAX5130/31 toc-18
TEMPERATURE (°C)
SHUTDOWN CURRENT (
µ A)
0.5
-1.5
0.1 10 100
MAX5131
FULL-SCALE OUTPUT vs. RESISTIVE LOAD
0
-0.5
-1.0
MAX5130/31 toc-20
RESISTOR (k Ω )
FULL-SCALE ERROR (LSB)
1
CS
2V/div
OUT
500mV/div
2 µ s/div
MAX5131
DYNAMIC RESPONSE RISE TIME
MAX5130/31-21
Typical Operating Characteristics (continued)
(V DD = +5V (MAX5130), V DD = +3V (MAX5131), R L = 5k Ω , C L = 100pF, OS = AGND, T
A
= +25°C, unless otherwise noted.)
