MAX5250
Low-Power, Quad, 10-Bit Voltage-Output DAC
with Serial Interface
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
DD
= +5V ±10%, AGND = DGND = 0V, REFAB = REFCD = 2.5V, R
L
= 5k
Ω
, C
L
= 100pF, T
A
= T
MIN
to T
MAX
, unless otherwise
noted. Typical values are at T
A
= +25°C. Output buffer connected in unity-gain configuration (Figure 9).)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD
to AGND............................................................-0.3V to +6V
V
DD
to DGND ...........................................................-0.3V to +6V
AGND to DGND ..................................................................±0.3V
REFAB, REFCD to AGND ...........................-0.3V to (V
DD
+ 0.3V)
OUT_, FB_ to AGND...................................-0.3V to (V
DD
+ 0.3V)
Digital Inputs to DGND.............................................-0.3V to +6V
DOUT, UPO to DGND ................................-0.3V to (V
DD
+ 0.3V)
Continuous Current into Any Pin.......................................±20mA
Continuous Power Dissipation (T
A
= +70°C)
Plastic DIP (derate 8.00mW/°C above +70°C) .................640mW
SSOP (derate 8.00mW/°C above +70°C) ......................640mW
CERDIP (derate 11.11mW/°C above +70°C) .................889mW
Operating Temperature Ranges
MAX5250_C_P ......................................................0°C to +70°C
MAX5250_E_P ...................................................-40°C to +85°C
MAX5250BMJP ................................................-55°C to +125°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10sec) .............................+300°C
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
Offset-Error Tempco
6
ppm/°C
Offset Error
V
OS
±6.0
mV
Differential Nonlinearity
DNL
±1.0
LSB
Integral Nonlinearity
(Note 1)
INL
±1.0
LSB
Gain Error (Note 1)
GE
±1.0
LSB
Gain-Error Tempco
1
ppm/°C
Power-Supply Rejection Ratio
PSRR
100
800
µV/V
Resolution
N
10
Bits
±0.25
±0.5
Reference Input Range
V
REF
0
V
DD
- 1.4
V
Reference Input Resistance
R
REF
10
k
Ω
Reference -3dB Bandwidth
650
kHz
Signal-to-Noise Plus
Distortion Ratio
SINAD
72
dB
V
REF
= 0.67Vp-p
V
REF
= 1Vp-p at 25kHz, code = full scale
Reference Feedthrough
-84
dB
Input code = all 0s, V
REF
= 3.6Vp-p at 1kHz
CONDITIONS
Code dependent, minimum at code 554 hex
Guaranteed monotonic
MAX5250B
4.5V
≤
V
DD
≤
5.5V
MAX5250A
STATIC PERFORMANCE—ANALOG SECTION
REFERENCE INPUT
MULTIPLYING-MODE PERFORMANCE
