register is not loaded. DOUT is high impedance during
a WRITE operation. Figure 4 shows the write cycle.

For single byte commands such as OSHT and SPOR,
the operation need only be 7 bits long where the
READ/WRITE bit is omitted. Here the command is
loaded into the shift register on the rising edge of SC
and the command is decoded during the high period of
the 7th clock pulse. The 7th falling edge of SC shifts the
command from the shift register to the appropriate reg-
ister. CS can then go high after the SC low to CS high
hold time t

CSH

(see SPI AC Timing, Electrical Char-

acteristics). Figure 5 shows the timing waveforms for
the MAX6661’s SPI interface.

Remote Temperature Data Register

Two registers, at addresses 81h and 83h, store the
measured temperature data from the remote diode. The
data format for the remote-diode temperature is 10 bits
+ sign, with each LSB corresponding to 0.125°C, in
two’s complement format (Table 3). Register 83h con-
tains the sign bit and the first 7 bits. Bits 7, 6, and 5 of

register 81h are the 3LSBs. If the two registers are not
read immediately, one after the other, their contents
may be the result of two different temperature measure-
ments, leading to erroneous temperature data. For this
reason, a parity bit has been added to the 81h register.
Bit 4 of this is zero if the data in 81h and 83h are from
the same temperature conversion and 83h is read first.
Otherwise, bit 4 is one. The remaining bits are don’t
cares. When reading temperature data, register 83h
must be read first.

Alarm Threshold Registers

The MAX6661 provides four alarm threshold registers
that can be programmed with a two’s complement tem-
perature value with each LSB corresponding to 1°C.
The registers are T

HIGH

, T

LOW

, T

MAX

, and T

HYST

. If the

measured temperature equals or exceeds T

HIGH

, or is

less than T

LOW

, an ALERT interrupt is asserted. If the

measured temperature equals or exceeds T

MAX

, the

OVERT output is asserted (see the Overtemperature
Output

OVERT

section). The POR state for T

HIGH

is

MAX6661

Remote Temperature-Controlled Fan-Speed

Regulator with SPI-Compatible Interface

_______________________________________________________________________________________

9

REGISTERS

COMMAND

POR STATE

FUNCTION

RRL

81h

00000000

Read Remote Temperature Low Byte (3MSBs)

RRH

83h

00000000

Read Remote Temperature High Byte (Sign Bit and First 7 Bits)

RSL

85h

00000000

Read Status Byte

RCL/WCL

87h/92h

00000000

Read/Write Configuration Byte

RFCR/WFCR

89h/94h

00000010

Read/Write Fan-Conversion Rate Byte

RTMAX/WTMAX

A1h/A4h

01100100 (+100

°C)

Read/Write Remote T

MAX

RTHYST/WTHYST

A3h/A6h

01011111 (+95

°C)

Read/Write Remote T

HYST

RTHIGH/WTHIGH

8Fh/9Ah

01111111 (+127

°C)

Read/Write Remote T

HIGH

RTLOW/WTLOW

91h/9Ch

11001001 (-55

°C)

Read/Write Remote T

LOW

SPOR

F8h

N/A

Write Software POR

OSHT

9Eh

N/A

Write One-Shot Temperature Conversion

RTFAN/WTFAN

A9h/B2h

00111100 (+60

°C)

Read/Write Fan-Control Threshold Temperature T

FAN

RFSC/WFSC

ABh/B4h

00000000

Read/Write Fan-Speed Control

RFG/WFG

ADh/B6h

10000000

Read/Write Fan Gain

RFTP

AFh

00000000

Read Fan Tachometer Period

RFTCL/WFTPLP

B1h/B8h

11111111

Read/Write Fan Tachometer Period Limit (Fan-Failure Limit)

RFTD/WFTD

BBh/BCh

00000001

Read/Write Fan Tachometer Divisor

RFS/WFS

BFh/C0h

11111111

Read/Write Full-Scale Register

RM/WM

F5h/F6h

00000000

Read/Write Mode Register

ID CODE

FDh

01001101

Read Manufacturer ID Code

ID CODE

FFh

00001001

Read Device ID Code

Table 2. MAX6661 Command-Byte Bit Assignments
