Package Information
QSOP.EPS
Pin Configuration
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
V FAN TACH IN
SDIN
SCL
GAIN
DOUT
ALERT
CS
OVERT
TOP VIEW
MAX6661
V CC
DXP
N.C.
DXN
FAN
PGND
AGND
QSOP
