MAX8595Z/MAX8596Z

High-Efficiency, 32V Step-Up Converters
with T

A

Derating Option for 2 to 8 White LEDs

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

IN to GND .................................................................-0.3V to +6V
PGND to GND .......................................................-0.3V to +0.3V
LX, OUT to GND .....................................................-0.3V to +37V
CTRL to GND...................-0.3V to the lower of +6V or (V

IN

+ 2V)

COMP, CS to GND ......................................-0.3V to (V

IN

+ 0.3V)

I

LX

...................................................................................1.0A

RMS

Continuous Power Dissipation (T

A

= +70°C)

8-Pin TDFN 3mm x 3mm

(derate 24.4mW/°C above +70°C) ............................ 1950mW

Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C

ELECTRICAL CHARACTERISTICS

(V

IN

= 3.0V, L = 22µH, C

IN

= 2.2µF, C

OUT

= 0.1µF, C

COMP

= 0.1µF, R

SENSE

= 13

Ω, V

CTRL

= 1.5V,

T

A

= -40°C to +85°C

, unless other-

wise noted. Typical values are at T

A

= +25°C.) (Note 1)

PARAMETER

CONDITIONS

MIN

TYP

MAX

UNITS

Supply Voltage

2.6

5.5

V

UVLO Threshold

V

IN

rising or falling

2.10

2.38

2.55

V

UVLO Hysteresis

30

mV

Quiescent Current

No switching

0.5

0.7

mA

T

A

= +25

°C

0.3

2

Shutdown Supply Current

CTRL = GND,
V

OUT

= V

IN

T

A

= +85

°C

1

µA

OVLO Threshold

V

OUT

rising

32

34

36

V

OVLO Hysteresis

2

V

V

OUT

= 32V, V

CTRL

> 0.24V

9

20

35

T

A

= +25

°C

0.01

1

OUT Input Bias Current

OUT = IN, CTRL = GND

T

A

= +85

°C

0.1

µA

Output Voltage Range

(Note 2)

V

IN

-

V

D

32

V

ERROR AMPLIFIER

T

A

= +25

°C

0.295

0.300

0.305

T

A

= 0

°C to +85°C

0.292

0.300

0.308

CTRL to CS Regulation

V

CTRL

= 1.50V,

V

IN

= 2.6V to 5.5V

T

A

= -40

°C to +85°C

0.290

0.300

0.310

V

T

A

= +25

°C

0.01

1

CS Input Bias Current

V

CS

= V

CTRL

/ 5

T

A

= +85

°C

0.03

µA

MAX8595Z, V

CTRL

= 3.0V

310

330

347

T

A

= -40

°C to +25°C

330

345

360

T

A

= +42

°C

343

CS Maximum Brightness Clamp
Voltage

MAX8596Z,
V

CTRL

= 3.0V

T

A

= +85

°C

106.5

mV

MAX8595Z

1.65

CTRL Voltage for CS Maximum
Brightness Clamp

MAX8596Z

1.72

V

CS Derating Function Start
Temperature

MAX8596Z, V

CTRL

= 3.0V

+42

°C
