Inputs, outputs, controls
Trinity Reverb English Manual Version 1.0 11
Inputs, outputs, controls
continued
4
9 10 1
7 8
5 6
3 2
8. Reverb type selector
Use the Reverb type selector to choose the type
of reverb you want to work with.
The reverb types are described in the section
“Reverb types”.
9. Pre-delay length selector
“Pre-delay” is the time between the direct sound
and the onset of the reverb tail. To keep the di-
rect sound “in-your-face” – even with a long de-
cay time and a high mix setting –, use the long
pre-delay setting.
– Top position: short pre-delay
– Bottom position: long pre-delay
10. USB port
Use this standard Mini-B USB port to load new
TonePrints into the pedal or create your own
using the TonePrint Editor – it’s 100 % free of
charge! If there should be firmware updates for
this device, they can also be installed using this
port.
