12
9 OUTPUT Outputs the right channel
(STEREO) of the stereo effects signal.
10 BYPASS Switches the audio signal into or
around the effects circuitry.
11 EX. BYPASS By connecting a simple momentary
switch here, the bypass function can
be remote controlled.
12 LED INDICATOR The LED at the top of the unit
indicates the sweep rate (as set by
SPEED) with effect on.
In BYPASS mode the LED "glows" at a
low levels indicating "power on".
FRONT DESCRIPTION
13
Connect the input source (instrument, pick-up or high output
microphone) by a mono jack cord to the Input jack.
The amplification used (amp(s), mixer) should be
connected by a mono jack cord(s) to: Output jack if you are
using one amp or a mono mixer. Both Output jacks - if you are
using two amps or a stereo mixer.
The TC SCF has a built-in power supply, which
should be connected to an AC "wall outlet".
GETTING STARTED
