Input Section
Input connector
Input impedance
Gain range
Tone control
Bass
Low Mid
High Mid
Treble
Tweeter Tone
Tube Tone
Spectra Comp
User Memories
Tuner
Tuning range
Mute
Master Level /
Headphones Output
HP Out Impedance
Mains supply
Power rating
1/4” jack
1 MOhm / 100 pF
-96 to 36dB
Center Freq: 100Hz (Gain: +15/-24dB)
Center Freq: 335Hz (Gain: +15/-24dB)
Center Freq: 900Hz (Gain: +15/-24dB)
Center Freq: 1600Hz @ Gain: -24 to 0dB; 4000Hz
@ Gain 0 to +15dB
0 to 10, L-PAD Cabinet Recreation
0 to 10, Tube amp Recreation
3 band Spectral Compression
3 memory locations storing all front panel controls
except Mute & Master Level
Bass Tuner, “On” when muted
B0 (30.87Hz) to G4 (392.00Hz)
Mutes speaker out, Phones out and Balanced out
Studio quality headphone amp
40 to 600 Ohm
100 - 120V~ or 220 - 240V~ 50/60Hz (65W @ 1/8
of Max. Output)
500w (1000w Peak)
16
Speaker output
Balanced output
Bal. Out Max.
Bal. Out Optimal Load
Impedance
Rehearsal input
Operating/Storage
Temperature:
Humidity:
Dimensions
Weight
Finish
Neutrik Speakon™
Balanced XLR, Pre/Post Pre-amp
+2dBu
600 Ohm
RCA, Left/Right input, fits to iPod ®
0° C to 50° C / -30° C to 70° C
Max. 90 % non-condensing
462 x 135 x 380 mm / 18.7” x 5.4” x 15.0”
13 kg / 29 pounds
Tolex covered. Handcrafted wooden box
appendIx – technIcal SpecIfIcatIonS
Due to continuous development, these
specifications are subject to change without notice.
