ENGLISH 12-0878
Using your flash bracket
1 Mount your camera to the flash
bracket by aligning the camera
with the mounting screw and
tightening the screw knob until the
camera is secure.
2 Mount your flash to the flash
bracket by sliding the flash into the
flash shoe. This separation
between your lens and flash helps
to eliminate red-eye and softens
shadows.
For vertical shots, rotate the flash
arm 180° to reposition the flash
above the lens.
Note: A TTL cord (not included) is
required to connect your flash to
your camera.
3 If necessary, mount the flash
bracket/camera assembly to a
tripod by aligning the screw knob
of the flash bracket with the screw
knob of the tripod. Tighten the
screw knob until the assembly is
secure.
Specifications
Opened dimension
Folded dimension
Net weight
Load capacity
5.6 Ч 1.26 Ч 6.6 in.
(14.2 Ч 3.2 Ч 16. 7 cm)
2.4 Ч 1.5 Ч 6.7 in.
(6.0 Ч 3.8 Ч 16.9 cm)
6.35 oz. (180 g)
2.2 lbs. (1 kg)
Important safety instructions
• Do not store or expose your flash
bracket to excessive heat or cold, or
use near any flame or fire.
• Do not oil or grease any part of the
flash bracket.
• Do not use any solvents or thinners
to clean your flash bracket. Use only
a mild detergent and wipe dry with
only a soft, lint-free-cloth.
• Do not tear off the rubber blanket.
It protects both the bottom of your
camera and the bracket from
abrasion.
• Do not tear off the rubber pad. It
provides comfortable adjustments
for arm position.
• Do not exceed the 2.2 lbs. (1 kg)
load limit of this flash bracket.
One-year limited warranty
Visit www.rocketfishproducts.com
for details.
