9082-OM (V4.4) 9082 PRODUCT MANUAL 2-1
Chapter 2
Chapter 2
Installation and Setup
Overview
This chapter contains the following information:
• Installing the 9082 Into a Frame Slot (p. 2-1)
• Installing a Rear I/O Module (p. 2-3)
• Setting Up 9082 Network Remote Control (p. 2-6)
Installing the 9082 Into a Frame Slot
CAUTION
Heat and power distribution requirements within a frame may dictate specific
slot placement of cards. Cards with many heat-producing components should
be arranged to avoid areas of excess heat build-up, particularly in frames
using only convection cooling.
CAUTION
Note: If installing the 9082 in a slot with no rear I/O module, a Rear I/O Module is
required before cabling can be connected. Refer to Installing a Rear I/O Mod-
ule (p. 2-3) for rear I/O module installation procedure.
This device contains semiconductor devices which are
susceptible to serious damage from Electrostatic
Discharge (ESD). ESD damage may not be immediately
apparent and can affect the long-term reliability of the
device.
Avoid handling circuit boards in high static environments
such as carpeted areas, and when wearing synthetic fiber
clothing. Always use proper ESD handling precautions
and equipment when working on circuit boards and
related equipment.
