Page 16 of 22 9031 Owner’s Manual •••• (V 2.1)
Menu Item Format Description
Parameter Save Confirm
Saves the parameters as
preset.
Parameter Load Confirm
Loads parameters
previously saved.
Presets
Restart Parameters
to Factory Default
Confirm
Will load factory presets
and overwrite the save.
Menu Item Format Description
Composite
Y/C
YPbPr BetaCam
YPbPr MII
SD Input Type
YPbPr SMPTE
Selects the format of
input SD analog video, so
the decoder can properly
decode the signal.
GBR
HD Input Type
YPbPr
Selects the format of
input HD analog video.
Video Signal
Controls
SD Composite
Contains
0.0 or 7.5 IRE of Setup
Specifies the amount of
setup (pedestal) in the
input video. It will be
removed by the decoder.
Menu Item Format Description
Video Gain
Range 0-2000 Gain applied to Y (Luma).
1000 is unity.
Video Lift
Range (-999) – 999 Lift applied to Y (Luma),
in 10 bit code value.
Color Gain Range 0-2000
Gain applied to C
(Chroma). 1000 is unity.
Color Phase Range (–360) – 360
Phase of C (Chroma) in
degrees.
Video Proc
Reset to Unity Confirm
Resets all of the proc
controls to unity.
