Sunpak PZ42X - Manual (Page 3)

12
Description of Parts
To assist you to make settings such as autofocus when shooting a picture in the
dark or under low light, the IR auxiliary light is emitted when the shutter button of
the camera is depressed halfway. After the AF auxiliary light is emitted, autofocus
is activated and the focusing signal lights up, press the shutter button all the way
down to release the shutter.
When using a multi-point focusing camera, set the focusing points at the
center of the picture.
Using the AF Auxiliary Light
Built-in wide panel
Light emitting section
Battery cover
AF auxiliary light emitter
Lock ring
Shoe contact pin
LCD display panel
SEL (select) button
Ready lamp/Test button
MODE button
Power switch
