6. Layouts
PNEG-1831 60' Dura-Lok Plank and Support Manual 41
60' Dura-Lok Plank Floor Bundle Layout
NOTES:
1. Looking from end of the bundle where all plank edges are butted flush.
2. Two (2) identical bundles required for complete floor.
3. Plank banding and sub-banding denoted by grid lines in charts.
Plank Layout by Marking Plank Layout by Length
2B 1 2A 137 147 65
9B 7B 5B 3B 166 146 119-1/2 86-1/2
10A 8A 6A 4A 176 155 133-1/2 104
9A 7A 5A 3A 238 218 191-1/2 158-1/2
10B 8B 6B 4B 248 227 205-1/2 176
17B 15B 13B 11B 230 216 202 185
18A 16A 14A 12A 236 223 209 191
17A 15A 13A 11A 302 288 274 257
18B 16B 14B 12B 308 295 281 263
25B 23B 21B 19B 270 262 252 241
26A 24A 22A 20A 275 266 257 247
25A 23A 21A 19A 342 334 324 313
26B 24B 22B 20B 347 338 329 319
33B 31B 29B 27B 298 292 286 279
34A 32A 30A 28A 300 295 289 282
33A 31A 29A 27A 370 364 358 351
34B 32B 30B 28B 372 367 361 354
41B 39B 37B 35B 313 310 307 303
42A 40A 38A 36A 314 312 309 305
41A 39A 37A 35A 385 382 379 375
42B 40B 38B 36B 386 384 381 377
49B 47B 45B 43B 319 318 317 315
50A 48A 46A 44A 319 319 317-1/2 316
49A 47A 45A 43A 391 390 389 387
50B 48B 46B 44B 391 391 389-1/2 388
