4. Monorail Installation
18 PNEG-1831 60' Dura-Lok Plank and Support Manual
Monorail “Rail and Leg Spacing”/“Full Floor Leg Quantity” for 60' Bin Diameter
4.00"
Ring
2.66"
Ring
Eave Height (ft.) Rail Spacing
Reference
Page
Leg Spacing Leg Qty
3 4 11 26 See Page 38 23 891
4 6 16 26 See Page 38 21 971
5 8 22 26 See Page 38 19 1068
7 10 27 22 See Page 37 19 1210
9 12 33 22 See Page 37 18 1274
10 14 38 20 See Page 34 18 1393
11 16 43 20 See Page 34 17 1471
13 18 48 18 See Page 33 17 1601
14 20 54 18 See Page 33 17 1601
16 22 59 18 See Page 33 16 1697
17 24 64 17 See Page 30 16 1785
19 26 70 17 See Page 30 16 1785
20 28 75 16 See Page 29 16 1870
22 30 81 16 See Page 29 15 1989
23 32 86 16 See Page 29 15 1989
25 34 92 15 See Page 26 15 1984
27 37 100 15 See Page 26 15 1984
