8. Cut-Lok/Cor-Lok Floors for Non-GSI Bins
PNEG-529 Cor-Lok and Cut-Lok Flooring for Non-GSI Bin Diameter
21
Cut-Lok/Cor-Lok Floors for Non-GSI Bins (Continued)
High back flashing is included with the floor unless otherwise requested. If 17-1/4" grandstands are to be
used, low back flashing should be requested.
Alway start at the sidewall of the bin and work to the center of the bin.
* Plank will be centered at center of the bin.
38'-0" (37'-1") Diameter Bin
(“A” = 18' - 11-1/2")
1
2' - 7-1/2"
2
9' - 7-1/2"
3
13' - 1-1/2"
4
15'-11"
5
18'-2"
6
11'-1'
9'-1'
7
11' - 10-1/2"
9'-10"
8
12'-8"
10'-7"
9
13'-4"
11'-4"
10
13' - 11-1/2"
11' - 11-1/2"
11
14' - 6-1/2"
12' - 6-1/2"
12
15'-1"
13'-1"
13
15'-7"
13'-7"
14
16' - 0-1/2"
14' - 0-1/2"
15
16' - 5-1/2"
14' - 5-1/2"
16
16'-10"
14'-10"
17
17'-2"
15'-2"
18
17'-6"
15'-6"
19
17'-10"
15'-10"
20
18'-1"
16'-1"
21
18'-4"
16'-4"
22
18'-7"
16'-7"
23
18' - 9-1/2"
16' - 9-1/2"
24
19'-0"
17'-0"
25
19'-2"
17'-2"
26
19' - 3-1/2"
17' - 3-1/2"
27
19'-5"
17'-5"
28
19 '- 6-1/2"
17' - 6-1/2"
29
19' - 7-1/2"
17' - 7-1/2"
30
19' - 8-1/2"
17' - 8-1/2"
31
19'-9"
17'-9"
32
19' - 9-1/2"
17' - 9-1/2"
* 33
19'-10"
17'-10"
41'-0" (40'-2") Diameter Bin
("A" = 21' - 10-1/2")
1
3'-8"
2
10'-4"
3
13'-10"
4
16'-9"
5
19'-1"
6
21'-2"
7
12'-6"
10' - 5-1/2
8
13' - 2-1/2"
11'-2"
9
13' - 11-1/2"
11'-11"
10
14' - 7-1/2
12'-7"
11
15'-3"
13'-2'
12
15'-10"
13'-9"
13
16'-4"
14'-4"
14
16' - 9-1/2"
14' - 9-1/2"
15
17'-3"
15'-3"
16
17'-8"
15'-8"
17
18'-1"
16'-1"
18
18'-5"
16'-5"
19
18'-9"
16'-9"
20
19'-1"
17'-1"
21
19'-4"
17'-4"
22
19' - 7-1/2"
17' - 7-1/2"
23
19'-10"
17'-10"
24
20'-1"
18'-1"
25
20' - 3-1/2"
18' - 3-1/2"
26
20' - 5-1/2"
18' - 5-1/2"
27
20' - 7-1/2"
18' - 7-1/2"
28
20'-9"
18'-9"
29
20'-11"
18'-11"
30
21'-0"
19'-0"
31
21'-1"
19'-1"
32
21'-2"
19'-2"
33
21'-3"
19'-3"
34
21' - 3-1/2"
19' - 3-1/2"
35
21'-4"
19'-4"
