6. 345 Cut-Lok/20 Gauge Cor-Lok Floors for Non-GSI Bins

16

PNEG-529 Cor-Lok and Cut-Lok Flooring for Non-GSI Bin Diameter

Grandstand Support Requirements for Above Floors

Spacings and quantities of supports are shown below.

Diameter

6 Rings (16' 8 Eave)

7 Rings (19' 5 Eave)

8 Rings (22' 2 Eave)

Nom.

Act.

Spacing

# of Supports

Spacing

# of Supports

Spacing

# of Supports

19'

(18' 7)

52/26

136

50/25

140

48/24

144

22'

(21' 8)

52/26

177

48/24

188

46/23

194

25'

(24' 9)

50/25

238

48/24

245

44/22

262

28'

(27' 10)

50/25

300

46/23

320

44/22

330

31'

(30' 11)

50/25

370

46/23

390

44/22

410

34'

(34' 0)

48/24

460

46/23

480

44/22

490

38'

(37' 1)

48/24

550

46/23

560

42/21

610

41'

(40' 2)

48/24

640

44/22

680

42/21

710

44'

(43' 3)

46/23

770

44/22

790

42/21

820

50'

(49' 5)

46/23

1000

42/21

1070

42/21

1070
