4. Bolt and Nut Usage
PNEG-4030 40 Series 27' and 30' Diameter Bins
23
Hardware for 3 Post Sidewall Sheets on Bins that are 18' to 90' Diameter and
105' Bins that are 27 Rings and Shorter
Refer to the chart for the hardware requirements for 3 post sidewall sheet connections on bins
18' to 90' diameter. Refer to the chart for the hardware requirements for 3 post sidewall sheet connections
on bins 105' diameter that are 27 rings and shorter.
Gauge
Horizontal Seam
Bolt Size (Quantity)
Vertical Seam Bolt
Size (Quantity)
Stiffener to Sidewall
Bolt Size (Quantity)
Overlap Seam Bolt
Size (Quantity)
20
3/8" x 1" (10)
3/8" x 1" (24)
3/8" x 1" (12)
3/8" x 1" (2)
19
3/8" x 1" (10)
3/8" x 1" (24)
3/8" x 1" (12)
3/8" x 1" (2)
18
3/8" x 1" (10)
3/8" x 1" (24)
3/8" x 1" (12)
3/8" x 1" (2)
17
3/8" x 1" (10)
3/8" x 1" (36)
3/8" x 1" (12)
3/8" x 1" (2)
16
3/8" x 1" (10)
3/8" x 1" (36)
3/8" x 1" (12)
3/8" x 1" (2)
15
3/8" x 1" (22)
3/8" x 1" (48)
3/8" x 1" (12)
3/8" x 1" (2)
14
3/8" x 1" (22)
3/8" x 1" (48)
3/8" x 1" (12)
3/8" x 1" (2)
13
3/8" x 1" (22)
3/8" x 1" (48)
3/8" x 1" (12)
3/8" x 1" (2)
12
3/8" x 1" (22)
3/8" x 1" (48)
3/8" x 1" (12)
3/8" x 1" (2)
11
3/8" x 1" (22)
3/8" x 1" (48)
3/8" x 1" (12)
3/8" x 1" (2)
10
3/8" x 1" (22)
3/8" x 1" (48)
3/8" x 1" (12)
3/8" x 1" (2)
9
3/8" x 1" (22)
3/8" x 1" (48)
3/8" x 1-1/2" (12)
3/8" x 1-1/2" (2)
8
3/8" x 1" (22)
3/8" x 1" (48)
3/8" x 1-1/2" (12)
3/8" x 1-1/2" (2)
6
3/8" x 1-1/2" (22)
3/8" x 1-1/2" (48)
3/8" x 1-1/2" (12)
3/8" x 1-1/2" (2)
5
3/8" x 1-1/2" (22)
3/8" x 1-1/2" (48)
3/8" x 1-1/2" (12)
3/8" x 1-1/2" (2)
11L
3/8" x 1-1/2" (22)
3/8" x 1-1/2" (48)
3/8" x 1-1/2" (12)
3/8" x 1-1/2" (2)
10L
3/8" x 1-1/2" (22)
3/8" x 1-1/2" (48)
3/8" x 1-1/2" (12)
3/8" x 1-1/2" (2)
9L
3/8" x 1-1/2" (24)
7/16" x 1-1/2" (48)
3/8" x 1-1/2" (24)
3/8" x 1-1/2" (6)
8L
3/8" x 1-1/2" (24)
7/16" x 1-1/2" (48)
3/8" x 1-1/2" (24)
3/8" x 1-1/2" (6)
