6. Layouts
44
PNEG-1835 90' Dura-Lok Plank and Support Manual
90' Plank Layout for Manual
Plank #
Length
Plank A
In Inch
In Metric
Plank #
Length
Plank B
In Inch
In Metric
Plank #
Length
Plank C
In Inch
In Metric
1C
12"-4"
148
375.92
2A
12' - 5-1/2"
149-1/2
379.73
2B
6' - 5-1/2"
77-1/2
197.08
2C
3A
8'-10"
106
269.24
3B
14'-10"
178
452.65
3C
4A
16' - 9-1/2"
201-1/2
511.81
4B
10' - 9-1/2"
129-1/2
329.32
4C
5A
12' - 5-1/2"
149-1/2
379.73
5B
18' - 5-1/2"
221-1/2
563.27
5C
6A
19' - 11-1/2"
239-1/2
608.33
6B
13' - 11-1/2" 167-1/2
425.95
6C
7A
15'-4"
184
467.36
7B
21'-4"
256
651.01
7C
8A
5'-1"
61
154.94
8B
4'-1"
49
124.61
8C
30'-0"
360
914.4
9A
5' - 2-1/2"
62-1/2
158.75
9B
6' - 2-1/2"
74-1/2
189.45
9C
30'-0"
360
914.4
10A
7' - 3-1/2"
87-1/2
222.25
10B
6' - 3-1/2"
75-1/2
192.00
10C
30'-0"
360
914.4
11A
7' - 3-1/2"
87-1/2
222.25
11B
8' - 3-1/2"
99-1/2
253.03
11C
30'-0"
360
914.4
12A
9'-3"
111
281.94
12B
8'-3"
99
251.76
12C
30'-0"
360
914.4
13A
9'-2"
110
279.4
13B
10'-2"
122
310.25
13C
30'-0"
360
914.4
14A
11'-1/2"
132-1/2
336.55
14B
10'-1/2"
120-1/2
306.43
14C
30'-0"
360
914.4
15A
10'-10"
130
330.2
15B
11'-10"
142
361.11
15C
30'-0"
360
914.4
16A
12' - 7-1/2"
151-1/2
384.81
16B
11' - 7-1/2"
139-1/2
354.75
16C
30'-0"
360
914.4
17A
12' - 4-1/2"
148-1/2
377.19
17B
13' - 4-1/2"
160-1/2
408.15
17C
30'-0"
360
914.4
18A
14'-1"
169
429.26
18B
13'-1"
157
399.25
18C
30'-0"
360
914.4
19A
13' - 9-1/2"
165-1/2
420.37
19B
14' - 9-1/2"
177-1/2
451.38
19C
30'-0"
360
914.4
20A
15' - 5-1/2"
185-1/2
471.17
20B
14' - 5-1/2"
173-1/2
441.21
20C
30'-0"
360
914.4
21A
15'-1"
181
459.74
21B
16'-1"
193
490.80
21C
30'-0"
360
914.4
22A
16' - 8-1/2"
200-1/2
509.27
22B
15' - 8-1/2"
188-1/2
479.36
22C
30'-0"
360
914.4
23A
16' - 3-1/2"
195-1/2
496.57
23B
17' - 3-1/2"
207-1/2
527.67
23C
30'-0"
360
914.4
24A
17'-10"
214
543.56
24B
16'-10"
202
513.69
24C
30'-0"
360
914.4
25A
17' - 4-1/2"
208-1/2
529.59
25B
18' - 4-1/2"
220-1/2
560.73
25C
30'-0"
360
914.4
26A
18'-11"
227
576.58
26B
17'-11"
215
546.75
26C
30'-0"
360
914.4
27A
18'-5"
221
561.34
27B
19'-5"
233
592.52
27C
30'-0"
360
914.4
28A
19'-11"
239
607.06
28B
18'-11"
227
577.26
28C
30'-0"
360
914.4
29A
19'-5"
233
591.82
29B
20'-5"
245
623.04
29C
30'-0"
360
914.4
30A
20' - 10-1/2"
250-1/2
636.27
30B
19' - 10-1/2" 238-1/2
606.51
30C
30'-0"
360
914.4
31A
20' - 3-1/2"
243-1/2
618.49
31B
21' - 3-1/2"
255-1/2
649.74
31C
30'-0"
360
914.4
32A
21'-9"
261
662.94
32B
20'-9"
249
633.21
32C
30'-0"
360
914.4
33A
21'-2"
254
645.16
33B
22'-2"
266
676.44
33C
30'-0"
360
914.4
34A
22' - 6-1/2"
270-1/2
687.07
34B
21' - 6-1/2"
258-1/2
657.37
34C
30'-0"
360
914.4
35A
21' - 11-1/2"
263-1/2
669.29
35B
22' - 11-1/2" 275-1/2
700.60
35C
30'-0"
360
914.4
36A
23'-4"
280
711.2
36B
22'-4"
268
681.52
36C
30'-0"
360
914.4
37A
22'-8"
272
690.88
37B
23'-8"
284
722.21
37C
30'-0"
360
914.4
38A
24'-1/2"
288-1/2
732.79
38B
23'-1/2"
276-1/2
703.14
38C
30'-0"
360
914.4
