SPECIFICATIONS
Available Colors & Finish
• Chrome
• Other: Refer to Price List for
additional finish
SD113001/11-09.01
Specific Features: Submitted Model No.:
EXTENSION KIT FOR CERAMIC MIXING VALVE (D112, D113 & D115) EXTENSION KIT FOR CERAMIC MIXING VALVE (D112, D113 & D115)
D 113001
Description
• Extended parts to allow deeper
installation of ceramic pressure balance
valve within wall
Warranty
Danze products are covered by a
manufacturer's limited "lifetime" warranty
for manufacturing defects.
Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA WWW.DANZE.COM
Standards
• CSA B125
• Listed IAPMO/UPC
2 1/16"
(53mm)
3/4"
(19mm)
5"
(127mm)
2 7/16"
(62mm)
Ш1 3/4"
(Ш45mm)
1 5/8"
(42mm)
2 3/16" (56mm)
2 9/16"
(65mm)
1 3/8"
(35mm)
Ш1/2"
(Ш12mm)
Ш3/8"
(Ш10mm)
4 7/16"
(1
12mm)
Ш11/16"
(Ш17mm)
1 11/16"
(43mm)
4 3/16"
(107mm)
5/8"-18UNF
W3/16"-24
W3/16"-24
W3/16"-24
