SDC037350/09-09.01 Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA danze.com
Submittal Information:
Contractor: Contact #:
Job Name: Location:
DC037350 DC037350
SPECIFICATIONS
Description
ZIGA ZAGA ® VESSEL LAVATORY ZIGA ZAGA ® VESSEL LAVATORY
Colors Available
Model
DC037350
IMPORTANT: Dimensions of fixtures are nominal and may vary within the range of tolerance
established by ASME Standard A112.19.2. These measurements are subject to change or
cancellation. No responsibility is assumed for use of superseded or voided pages.
Warranty
Five Year Limited Warranty (Vitreous China)
Standards
Technical lnformation
• 24"w x 15 3/8"d x 5 5/8"h
• Faucet holes: none
• CSA B45.1
• UPC
• ASME A112.19.2
• White (WH)
Fixture:
Drain hole 1 3/4" (4.4 cm)
Basin area 20 1/4" (51.4 cm) x 14 5/8" (37.1 cm)
Basin depth 3 1/2" (8.8 cm)
FINISHED
FLOOR
3/8 " HOT
1 1/4 " WASTE
3/8 " COLD
24"
11"
20 3/4 "
20 1/4 "
14 5/8 "
15 3/8 "
16 7/8 "
18 3/8 "
7 3/4 "
8"
3 3/4 "
5 5/8 " 5 5/8 "
