Danze D151001B - Installation Manual User Manual
Page 12
2.
Installez la nouvelle cartouche de régulation du débit (1), l’adaptateur long (2), la longue tige (3)
et la vis (4) dans l’ordre indiqué dans l’illustration ci-dessous.
3.
Installez le long manchon (5) et la longue tige de la cartouche thermostatique (6). Remettez en
place la vis existante (7).
1
2
3
4
5
6
7
12
