Danze D221544 - Spec Sheets - Manual

SD221544/11-09.01 Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA danze.com
Contractor: Contact #:
Job Name: Location:
Submittal Information:
D221544 D221544
SPECIFICATIONS
Warranty
Danze products are covered by a manufacturer’s
limited "lifetime" warranty for manufacturing defects.
Description
• Ceramic disc valve
• 8 ¾" high swivel spout, 5 ½" spout length
• Natural water stream
• Metal touch down drain assembly
• Single hole mount
SIRIUS™ SINGLE HANDLE LAVATORY FAUCET SIRIUS™ SINGLE HANDLE LAVATORY FAUCET
Finishes Available
Model
D221544 (Replaces D223144 series)
Standards
• UPC/cUPC
• NSF 61-9
• Energy policy act of 1992
• CSA B125
• ADA Accessibility Guidelines for
Buildings and Facilities -
4.27.4 Controls and Mechanisms
• ASME A112.18.1
• Meets CA AB-1953
MEETS
CA AB-1953
Less than 0.25% lead content
Flow Rate
• Chrome
• Other: Refer to Price List for
additional
finish
1 1/4"-18UNEF
3/8"Compression
9/16"-24UNEF
1 7/16"-18UNEF
Ш1 7/8"
(Ш48mm)
2 1/4" (57mm)
3 5/8"
(92mm)
5 1/2"
(140mm)
8 1
1
/16"
(220mm)
5 13/16"
(148mm)
25°
45° 45°
8 1/2"
(216mm)
Ш2 1/8"
(Ш54mm)
1 1/8"~1 13/16"
(28~46mm)
Ш1 1/4"
(Ш32mm)
1/2"(min)
13mm(min)
15°
2 1
1
/16"
(68mm)
Ш1 1/2"
(Ш38mm)
3 1/16" (78mm)
4 1/16"
(103mm)
1 3/16"
(30mm)
19 5/16"
(490mm)
"
(56mm)
2 3/16
1/16"~2"
(1~51mm)
0.5
1
1.5
2
20 40 60 80
PSI
GPM
