Danze D402059 - Manual

SD402059/05-13.01 Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA danze.com
Contractor: Contact #:
Job Name: Location:
Submittal Information:
402059 D 402059 D
SPECIFICATIONS
Warranty
Danze products are covered by a manufacturer’s
limited "lifetime" warranty for manufacturing defects.
Description
• High-rise swivel spout
• Ceramic disc valves
• 2 hole mount
• 9 1/4″ high sport,8 1/4″ spout length
PARMA™ TWO HANDLE KITCHEN FAUCET PARMA™ TWO HANDLE KITCHEN FAUCET
Finishes Available
Model
D402059
Standards
• Chrome
• Stainless Steel
• NSF 61-9
• Energy Policy Act of 1992
• NSF/ANSI 372
NSF/ANSI 372
• ASME A112.18.1M/A112.18.1
Certified to NSF/ANSI 61
Section 9
3 15/16" (100mm) Ш2 1/8"
(Ш54mm)
6 1/8"
(155mm)
5 7/8"
(150mm)
13 3/8"
(339.5mm)
1/16"~2 1/4"
(1mm~57mm)
9 5/16" (236mm)
8 5/16"
(211mm)
30°
20°
5 1/2"
(139mm)
6 5/16" (161mm)
3/8" Compression
1 1/4”-18UNEF
1/2”-14NPSM
9/16"-24UNEF
Flow Rate
0.5
1
1.5
2
20 40 60 80
PSI
GPM
2.5
