SINGLE HANDLE PRESSURE BALANCE TUB & SHOWER VALVES SINGLE HANDLE PRESSURE BALANCE TUB & SHOWER VALVES
SPECIFICATIONS
SD503066/11-08.03
Specific Features: Submitted Model No.:
Critical Dimensions : Rough-in valve D112000BT (w/stops) & D115000BT (w/o stops)
Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA WWW.DANZE.COM
W/SCREWDRIVER STOPS
W/DIVERTER & STOPS
1/2"-14NPT
PLASTIC GUARD
6 3/4"
(172mm)
3 1
1/16"
(93mm)
1 1
1/16"
(43mm)
1 9/16"
(39mm)
3/8"Max
(10mm)
11/16"
(18mm)
ш6"
(ш152mm)
26"
(660mm)
ш5/8"
(ш16mm)
1 1/16" (27mm)
3 1/16"
(77mm)
2 3/4"
(70mm)
4 1/4"
(108mm)
1/2"-14NPT
PLASTIC GUARD
13/16"
(21mm)
1 9/16"
(39mm) 3/8"Max
(10mm)
11/16"
(18mm)
ш6"
(ш152mm)
26"
(660mm)
1 1/16"
(27mm)
ш5/8"
(ш16mm)
3 1/16"
(77mm)
2 3/4"
(70mm)
3 9/16"
(91mm)
3 5/8"
(92mm)
