Danze D130001B - Spec Sheets - Manual (Page 2)

Deep Wall Extension Kit For 1/ 2 " Shower Diverter Valve Deep Wall Extension Kit For 1/ 2" Shower Diverter Valve
SPECIFICATIONS
SD130001B/07-08.01
Specific Features: Submitted Model No.:
Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA WWW.DANZE.COM
2 7/16~2 15/16"
(62.5~75.5mm)
1 5/8~2 1/8"
(41~54mm)
3 1/8~3 5/8"
(80~93mm)
3 7/16"
(87mm)
1/8"
(3mm)
Ш
1
9/16"
Ш(40mm)
2 3/16"
(55mm)
Ш
1
7/8"
Ш(48mm)
1 11/16"
(43mm)
Ш
1/2"
(Ш12mm)
1 5/8"
(42mm)
Ш
13/16"
(Ш20mm)
1 5/8"
(42mm)
4 3/16~4 9/16"
(106~115mm)
3 7/16~3 13/16"
(88.5~97.5mm)
1 3/4~2 1/8"
(44~53mm)
W3/16"-24
11/16"-20UN
11/16"-20UN
NORMALRough-in Range（3 1/8"-3 5/8"
，80-93mm) Extension kit for deep wall
installation unused.
NORMALRough-in Range（4 3/16"-4
9/16"，106-115mm) Extension kit for
deep wall installation used.
Diverter cartridge
Nut
Long screw
Long shank
Long stem
extension
Kit B (Extended rough-in range 4 3/16~4 9/16)
