16
97240 v.6.0
Note: If your vehicle is equipped with
a Banks Diesel tuner, optional tuner-
to- SpeedBrake cable will be needed
(P/N 55412). See Figure 14. Disconnect
the 6-pin terminal connections between
Banks oBD II Interface Cable and Banks
Diesel tuner. Connect the oBD II 6-pin
male connector to the optional tuner-
to-SpeedBrake 6-pin female connector.
Connect the two (2) wire male connector
to the Diesel tuner female 6-pin
connector and connect the four (4) wire
male connector to the SpeedBrake
female 6-pin connector.
8.
Locate the RJ12 cable (similar to
telephone connector) on your Banks
OBDII interface cable
. See figure 15.
9.
Locate Banks iQ Bridge Module and
connect the RJ12 connector into the
Bridge Module. See figure 16.
10.
Route the Banks iQ USB interface
cable from the Banks iQ Bridge Module
under the dash and out through the fuse
access panel opening. The cable can be
slid under the door frame’s seal and run
up to the top of the dash. Pull enough
cable to reach the Banks iQ and connect
it to the USB receptacle on the left side
of Banks iQ. See figure 12. Snap the
fuse access panel back in place making
sure not to pinch the wire.
WaRNING: THE CHaRGING CaBLE
CoNNECTED To THE BaNkS IQ IS
DESIGNED To SUPPLY a CoNSTaNT
LoW-voLTaGE PoWER SoURCE
(+5vDC) To THE BaNkS IQ aND IS
“LIvE” aS LoNG aS THE SYSTEM’S
oBD II INTERfaCE CaBLE oR BaNkS
WIRING HaRNESS IS CoMPLETELY
INSTaLLED aND THE USB CaBLE
CoNNECToR IS PLUGGED INTo
BaNkS IQ. aLTHoUGH THIS
CHaRGING CaBLE IS SHoRT aND
ITS CIRCUITRY IS fUSE-PRoTECTED,
THE USER IS ExPECTED To TakE
aPPRoPRIaTE MEaSURES To
PREvENT SMaLL CHILDREN aND/
oR PETS fRoM CoNTaCT WITH aNY
PaRT of THIS SYSTEM.
11.
Secure Banks iQ Bridge Module
under the dash to any dash frame
support using the supplied cable ties.
Use the cable tie support loops on the
side of the Bridge Module to securely
fasten it under the dash.
12.
Route all wiring away from any
pedals or other moving components.
Using the cable ties supplied, secure the
wiring under the dash.
13.
Reinstall the lower knee panel back
in place with the factory hardware. Tuck
any excess cable behind it for a clean
appearance.
-END, SECTION 2-
